LSAW steel pipe ASTM A572

Longitudinal Submerged-Arc Welded Steel Pipe

• Process: LSAW - UO(UOE), RB(RBE), JCO(JCOE, COE); DSAW - Double Submerged Arc Welded
• Usage: Used for low pressure liquid delivery, such as water, gas, and oil.
• Standard: API 5L, API 5CT, ASTM 53, EN10217, DIN 2458. IS 3589, GB/T3091, GB/T9711
• Certificate: API 5L PSL1 / PSL2, API 5CT
• Out Diameter: 323.9mm -1820mm(12\'\'-72\'\')
• Wall Thickness:5.0 - 50mm
• Length:6 – 12m

• Steel Grade:
• API 5L: GR B, X42, X46, X56, X60, X65, X70 ASTM A53: GR A, GR B, GR C EN: S275, S275JR, S355JRH, S355J2H GB: Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555

• Surface: Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating, Bitumen Coating, Black Oil coating as per customer’s requirement

• Test: Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test.
• Mill Test Certificate: EN 10204 / 3.1B
