General Specification

1.Main Features

Operationg Syetem	Window 7
Monitor	12.1 inch LED high-resolution monitor
Scanning Mode	B, B/B, 4B, B/M, M, 3D Image Reconstruction
Keyboard	Back-lit Silicone Keyboard (option)
Cine Loop	Up to1024 frames
Gain	0-255dB
TGC	8 segment
Scanning Depth	Up to240mm
Dynamic Range	20-150dB
Pseudo-color	40, or customized
Body Marking	140
Focus	4
Magnification	0.8-6.0
Probe Connector	2
Language	Chinese/English/Spanish
Matching Printer	Laser/Vedio/Inkjet/Thermal printer
Peripheral Port	USB, DICOM3.0, RS232, VGA, VCR, PAL-D
Measurement & Calculation	B-mode: Distance, Perimeter, Area, Volume, Angle, Histogram, Cross Section, Hip Joint Angle M-mode: Heart Rate, Time, Gradient
Image Processing Technologies	THI, Pre-process, Post-process, Dynamic Range, Contrast, Frame Correlation, Average Line, Edge Enhancement, Black-white Change over, Gray-scale Transformation&Adjustment, Brightness, Gamma Correction

2. Applications
Abdominal(Liver,Gallbladder,Spleen, Kidney, Pancreas)
Gynecology(Uterus, Cervix Uterus, Endometrium, Ovary, Ovarian Follicle, Hydatoncus, Enclosed Mass)

Obstetric(AC, BPD, CRL, FL, THD, GS, OFD, HUMERUS, TIDIA, ULNA, HC, TAD, APTD, FTA, AFI, Analytic report of fetus and the growth curve)
Cardiology(LV, LV Function, Aorta, Mitral, Valve)
Urology(Left Renal Volume, Right Renal Volume, RUV, Prostate kidney)
Small Parts(Ophthalmology, Thyroid, Jaw and Face)

3.Standard Configuration
Main system unit, 3.5MHz Convex probe, Lithium battery, Power adapter, Carrier suitcase, User manual and disc

4. OptionalItems
Biopsy Bracket

5.Probes Selection
3.5 MHz Convex Probe (3.5-14MHz variable frequency )

7.5 MHz Linear Probe (3.5-14MHz variable frequency )

7.5 MHz Transvaginal Probe (3-10MHz variable frequency)

5.0 MHz Micro-Convex Probe (2-6MHz variable frequency)

7.5 MHzRectalProbe(80 elements)

6. Advanced Technologies
PC platform
Full DigitalUltrasonic Kernel Engine
One Touch Optimizer
Tissue Harmonic Imaging
3D ImagingReconstruction
DICOM3.0
