Angle Bending Machine

Minimum Order
1
Packaging
N/A
Delivery
15 Days

Angle bending machine, one of the Angle processing machinery. The working mechanism is a horizontal working disk rotating on the vertical axis, placing the Angle in the dotted position of the diagram, and the underwrite shaft fixed to the machine tool. The center pin and the bent pin are mounted on the working disc and the Angle is bent when the disc is rotating. In order to bend the Angle of various diameters, there are several holes in the working disk, which can be used to insert the bending pin axis, and the center pin axis of different diameters can be changed accordingly.

From the Basic Principle of Angle Sheet Bending Machine

we can divide the CNC Angle machine into three kinds.

1. Worm and gear Angle sheet bending machine
The motor provides a power base for the wheel movement, and the internal straight gear and worm gear can be used to rotate the working disk after it is slowed down. The working disk of the bending machine contains nine pores, one of which is used to insert the central axis, and most of the rest is used to insert the shaft. In order to increase the flexibility of the instrument, it is easy to move the Angle, and there are also feeding rolls on both sides of the workbench. Put an Angle on the inside of the iron shaft, which causes the Angle to bend.
2. Gear Angle Sheet bending machine
This
Angle sheet bending machineis the control of Angle to achieve the purpose of Angle bending. After the degree of Angle bending is determined by itself, the Angle primary mechanism and several limit pins work together. When the Angle of bending is bent to the degree of bending, the limit pin turns on the switch and the motor stops and reverses, eventually reaching the original position and completing the entire bending process.
3. Hydraulic Angle cut off the bending machine
The operation of the hydraulic pump is driven by the electric motor, and a group of pistons is used for the rotation of the bending work disk by using a hydraulic pump. Of course, after completing the bending process, the device's cutting mechanism also needs to be noted. We want to borrow the power of the spring to separate the central valve from the hydraulic pump, and the high-pressure oil is flowing back into the tank.
