Medium Power 300/500W metal fiber laser cutting machine HS-F1325

Fiber laser source is the most advanced laser source for metal cutting. HSG LASER 300/500W metal fiber laser cutting machine cut 5mm stainless and 6mm mild steel. We adhere to “manufacture the best 500W metal laser cutting beds in China” for business purposes. Buy this machine will bring you large benefit.

Metal laser cutting machine introduction:

1. Control system and software introduction

This control system is composed by the industrial PC, center control card, controller display of power supply, professional control software. The PC is installed into the control box, the center control card receive the orders from the software and execute it. Through the controller display of power supply, we light the lamps; adjust the cutting parameters like current, frequency, pulse width according to different materials and plate thickness. And through the control software, we input the cutting file, add the lead line, give kerfs compensation, and fix cutting position and so on.

2. Cooling system or chiller introduction

We will supply 7P chiller for the customer, it has much better cooling effect compare with 5P, this chiller have some advanced function, like the protector for phase error, phase lack, water pressure alarm, water filter, water temperature setting.

3. Motion system introduction

This system is composed by the double lead screw; double track, Panasonic motor and Panasonic diver. Which ensure the high cutting precision and high cutting speed.

4. Laser system introduction

The YAG laser system is composed by the full-reflector, laser cavity, crystal rod, semi-reflector, expanding lens, 45 degree reflector, focus lens, protective lens, and laser power supply. The laser path will be adjusted well by the red light indication. The Ex. lamps will be lighted by the laser power supply, and the crystal will absorb and release the optical energy which transferred by those mirrors and lens.

The Fiber laser system is imported from Germany IPG Laser Company which not likes the YAG laser has so complicated laser path, the whole laser system is connected with the general power, and the optical energy will be transferred by the fiber cable.

Advantages of fiber laser cutting machines:

There is a lot of unique advantages about fiber laser cutting machines. Such as:

1. Free maintenance, lowest power consumption and longest working lifespan and the most important is highest accuracy and affiance during processing the metal materials. For the laser source, we import from the most famous company IPG/Coherent to ensure our machines good quality.

2. Long lifespan (100,000 hours) of the laser module (IPG laser source 300W, 500W for choice.)

3. Specialist for precisely Cutting Sheet Metal

4. Auto focus system to change focus length automatically while process uneven materials

5. Nesting Software provides efficiency and saving materials

6. Minimized burrs and roughness

7. Lowest maintenance cost and power consumption

8. Easy operation
