Butt Fusion Pipe Welding Machine (TPW630)CE
Product Quick Detail
- Packaging
- N/A
- Delivery
- 25 Days
Specifications
Pls feel free to contact: riyangfredy*hotmail.com or fredy*riyang-welding.com
Features:
∞Suitable for butt welding of PE, PP&PVDF pipes and pipe fittings on construction site or in workshop.
∞Consists of basic frame, hydraulic unit, electric planning tool, heating plate, support for planning tool and heating plate.
∞Removable cast Aluminum PTFE coated heating plate with separate temperature controlling system.
∞Removable case Aluminum Electrical planning tool with safety limitswitch.
∞Made of lightweight and high strength material.
∞Electrical hydraulic pump with controls, and quick release hoses.
∞Low starting pressure ensures reliable welding quality of smallpipe.
∞Changeable welding position enables to weld various fittings moreeasily.
∞Separate two-channel timer records time in soaking and coolingphases with time alarm.
∞High-accurate and shockproof pressure meter indicates clearerreadings.
∞International warranty 12months.
∞Tool box including spare blades, thermocouple, quick couplings, sealrings, spanner and screwdriver, etc.
Optional parts: Stub end device. Optional wheeled trolley is also available..
Specifications:
| Model | TPW630 |
| Welding Size(mm) | 315,400,450,500,560,630 |
| Sealing Deviation(mm) | ≤0.5 |
| TemperatureControl Range(degree) | 0~300 |
| Temperature Error(degree) | ±5 |
| Max.working pressure | 6.3Mpa |
| Working Voltage | 50HZ/380V |
| Heating Power | 9.2KW/380V |
| Power Of Planing Tool | 1.5KW/380V |
| Hydraulic Power | 1.5KW/380V |
| Total Weight | 600KG |
you can try welding machine to get through more products
- Country: China (Mainland)
- Business Type: Manufacturer,Trading Company
- Market:Africa,Middle East,Americas,Asia,Emerging Markets,Oceania
- Founded Year:2008
- Address:No. 789. Shenhua Road. Westlake District, Hangzhou
- Contact:Fredy Zhu
