Luminox O2 ppm Sensors Fluorescence-Based Optical Series

LuminOx O2 PPM Sensors
Fluorescence-based Optical Series

FEATURES
* Fluorescence–based optical technology
* Contains no hazardous materials; RoHS & REACH compliant
* Factory calibrated
* High accuracy
* Maintenance free
* Long life, non-depleting technology - can be stored in any oxygen %

BENEFITS
* Low power, long life due to non-depleting sensing principle
* Compact footprint

TECHNICAL SPECIFICATIONS
Supply voltage (Vs): 8-30V DC
Supply current (ls): <15mA Average; <50mA Peak
Output Type: RS232
Temperature
Operating: -30℃ to +60℃
Storage: -30℃ to +60℃
Humidity: 0-99% Rh (non-condensing)
Barometric pressure range: 260-1260mbar

OUTPUT VALUES
Oxygen range: -1000ppm
Oxygen pressure range: 0-1200µbar ppO2
Response time T90: < 30s (typical)
Accuracy:
ppO2: < 2% FS
Temperature： Indication only
Pressure: ±5mbar
O2: Determined by ppO2 & pressure accuracy
Resolution:
ppO2: 1mbar
Temperature: 0.1℃
Pressure: 1µbar
O2: 1ppm
Lifetime: > 5 years
