Honeycomb Sandwich Panels
Product Quick Detail
- 1
- set
- Minimum Order
- 1
- Packaging
- basic packging
- Delivery
- 15 Days
Specifications
| Color steel foam sandwich panel / Paper honeycomb sandwich panel | ||
| Type |
Color steel foam sandwich panel (overlap joint) All the screw and aluminum accessories are available |
|
| Dimensions | Thickness | 50-200mm |
| Width | 1150mm (effective width) | |
| Length | Less than 11.8m | |
| External face | Material | PPGI |
| Thickness | 0.3-0.7mm | |
| Thickness of the zinc | - | |
| Corrosion protection | Color coated | |
| Coating | Polyester | |
| Thickness of coating | 20 micron | |
| Color | According to the RAL | |
| Pattern | Nearly plain | |
| Insulation | Optional foam Material | EPS;Rock wool;PU |
| Thickness | 50-200mm | |
| Density | 15kg/m3 | |
| Thermal conductivity | ≤0.036W/m.K | |
| Internal face | Material | PPGI |
| Steel thickness | 0.3-0.7mm | |
| Color | Grey white or customized | |
| Corrosion protection | Color coated | |
| Coating | Polyester | |
| Thickness of coating | 7micron | |
| Pattern | Plain |
- Country: China (Mainland)
- Business Type:
- Market:
- Founded Year:1998
- Address:
- Contact:hao hai
