Stainless Steel Tube Mill Making Machine from China
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Features of the series equipment: high precision, high roll-exchange speed, die saving. According to the strip steel material and the mechanical properties, the tube is designed to proper hole-pattern type, to minimize the scratches by the roll on the strip steel surface and reasonably allocate the drive speed ratio, reduce the wear of the drive inside the unit, and save electricity.
Process of the series equipment: second generation, third generation and fourth generation of ZTF forming process
The main models include:
ERW273 Unit Series
ERW325 Unit Series
ERW406 Unit Series
ERW660 Unit Series
RW508 Unit Series
Star Products:
ZTF third-generation equipment is a type of higher cost performance at present. Compared to ZTF second-generation equipment, we creatively adopt the design without roller pad in the third-generation product, namely the opening and closing of the roll is adjusted online through the lead screw, so as to avoid various inconveniences and security risks for customers in die removal and replacement.
ERW 660 carbon steel HF Straight Welded Pipe production Line
I.Brief introduction
ERW660high frequency longitudinal welded pipe production line / pipe making machine / tube forming machine is designed to produce welded pipes of 325mm-660mm in OD and 6.0mm-20.0mm in wall thickness.
The plain technical flow of the production line
Uncoilingâ Shear & butt weldingâ Accumulatorâ Forming â HF weldingâ Removing outsaide burr â Cooling(air & water)â Sizingâ Cutting off(flying saw)â inspection â Packing â Warehousing
II. Basic Technical Information:
1.Specification of pipes
Pipe OD: 325mm-660mm Thickness: 6.0mm-20.0mm
Length: 6 -12m Length Tolerance: ±3mm
2.Raw Material:
Material: Carbon steel coil Q235B(ASTM GR·D,Ïs 230)
Width: 860mm-2000mm Thickness: 6.0mm-20.0mm
Coil ID:580-760mm
Coil OD: Max 2300mm
Coil Weight: 40t
3. Tube mill
Production Speed : 20 m/min
Production capacity: 150,000ton/year
Direction : left or right decided by customers.
Mill installed capacity : 1200 kw
Line Area : 350m(length) Ã35m (width)
Tube Bottom Passline (Above floor level) : 1000 mm
