China ERW426 Large round pipe mill
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Features of the series equipment: high precision, high roll-exchange speed, die saving. According to the strip steel material and the mechanical properties, the tube is designed to proper hole-pattern type, to minimize the scratches by the roll on the strip steel surface and reasonably allocate the drive speed ratio, reduce the wear of the drive inside the unit, and save electricity.
High frequency small round pipe/tube mill
ERW406 carbon steel HF Straight Welded Pipe production Line
I.Brief introduction
ERW406high frequency longitudinal welded pipe production line / pipe making machine / tube forming machine is designed to produce welded pipes of 219mm-406mm in OD and 6.0mm-16.0mm in wall thickness.
The plain technical flow of the production line
Uncoilingâ Shear & butt weldingâ Accumulatorâ Forming â HF weldingâ Removing outsaide burr â Cooling(air & water)â Sizingâ Cutting off(flying saw)â inspection â Packing â Warehousing
II. Basic Technical Information:
1.Specification of pipes
Pipe OD: 219mm-406mm Thickness: 6.0mm-16.0mm
Square & rectangle tube: 170mmÃ170mm â 330mmÃ330mm, Thickness: 6.0mm-15.0mm
Length: 6 -12m Length Tolerance: ±3mm
2.Raw Material:
Material: Carbon steel coil
Width: 520mm-1340mm Thickness: 6.0mm-16.0mm
Coil ID:580-760mm
Coil OD: Max 2300mm
Coil Weight: 35t
3. Tube mill
Production Speed : 30 m/min
Production capacity: 180,000ton/year
Direction : left or right decided by customers.
Mill installed capacity : 880 kw
Line Area : 160m(length) Ã16m (width)
Tube Bottom Passline (Above floor level) : 1000mm
