Original Xaar 1002 AMp Printhead
The Xaar 1002 AMp is the first of a new range of market-leading piezoelectric drop-on-demand printheads for Advanced Manufacturing applications.
The Xaar 1002 AMp is perfect for very small drop fluid deposition on an industrial scale and is capable of consistently jetting droplets as small as 1 pL for the production of fine features,
patterns and coatings. The combination of highly accurate, very small drops and unrivalled reliability enables the industrialisation of advanced manufacturing processes in sectors such as display,
PCB, semiconductors and photovoltaics.
Many applications require tight regulation of coating thicknesses, precise patterns and management of substrate surface characteristics. The Xaar 1002 AMp combines highly accurate drop placement,
consistent drop volume and high frequency jetting with variable drop size capability to deliver the precise fluid control essential for these processes.
Xaar 1002 AMp |
|
---|---|
âActive nozzles |
â1000 |
âPrint swathe width |
â70.5 mm |
âNumber of rows |
â2 |
âNozzle pitch (interleaved) |
â70.5 μm |
âDrop velocity*â |
â7 m/s |
âNozzle density |
â360 npi |
Print addressability (x,y)â |
ââ360 x 720 dpiâ |
âPrinthead weight (dry) |
â122 g |
âInk and fluid type |
âSolvent, UV, Oil |
âDrop volume* (at 8 levels) |
â1 - 3 pL |
âNumber of grey levels* |
Up to â8 |
âTypical firing frequency* |
â6 -12 kHz |
âDimensions (WxDxH) |
â125x31x6â1 mm |
