Y Type Strainer
Product Quick Detail
- Packaging
- standard
- Delivery
- 15 Days
Specifications
1. The stainless steel mesh hole is 2-6 microns, and others can be possible to choose.
2. Big filtration area, doubled-deck screen which is made of stainless steel, simple and firm structure.
3. Resistant to dirt, easy installation and convenient maintenance.
| Type | SY34-150-300LB | |
| Applicable Fluid | Water, Oil, Steam | |
| Applicable Inlet Pressure | 2.0~5.0Mpa | |
| Applicable Temperature | Max.T. 250℃ | |
| Connection Mode | ANSI B16.5 RF Flanged | |
| Hydrostatic Test | 3.0-7.0Mpa | |
| Material | Body, Cover | Cast Steel |
| Screen | Stainless Steel (304) | |
| Plug | Forged Steel(304) | |
| O-Ring/Gasket | O-Ring (NBR), Gasket(Asbestos) |
Y Type Strainer Dimension drawing
| DN | Size(in) | L | H | H1 | |
| DN20 | 3/4” | 150 | 80 | 115 | |
| DN25 | 1” | 160 | 90 | 125 | |
| DN32 | 1-1/4” | 18 | 110 | 145 | |
| DN40 | 1-1/2” | 200 | 135 | 173 | |
| DN50 | 2” | 210 | 160 | 210 | |
| DN65 | 2-1/2” | 245 | 185 | 243 | |
| DN80 | 3” | 270 | 190 | 290 | |
| DN100 | 4” | 320 | 45 | 390 | |
| DN125 | 5” | 360 | 290 | 430 | |
| DN150 | 6” | 430 | 350 | 510 | |
| DN200 | 8” | 500 | 415 | 595 | |
| DN250 | 10” | 600 | 545 | 780 | |
| SN300 | 12” | 700 | 670 | 875 | |
| DN350 | 14” | 750 | 735 | 1040 | |
| DN400 | 16” | 850 | 820 | 1220 | |
