Reefer Container

FOB Price
USD $600.00 / Piece
Place Of Origin
Shenzhen
Minimum Order
1
Packaging
N/A
Delivery
15Days
Reefer Management by CIMC Intelligent Technology Co., Ltd., Installed near the cooler controller, realize data interaction with the cooler controller through satellite positioning and cellular communication (optional LEO satellite communication), and monitor the process of container cold chain transportation.

Reefer container tracking can reduce costs (operation and maintenance) for container owners and cargo owners, improve cargo supervision capabilities, optimize deployment plans, reduce transportation risks and improve management efficiency for users.

Product Description
Support Four Coolers
It connects with Carrier, Cool King, Daikin and StarCool

Location tracking, Status monitoring
Reefer container's real-time location tracking (GPS), motion status monitoring, electronic fence function and power failure detection

Abnormal situation, Real-time alarm
Automatic alarms and notifications to effectively reduce the risk of product deterioration

The Advantage of Product
Reefer Guard can maintain normal standby battery life for a long time in the case of long-term power failure; secondly, Reefer reefer tracking device have a self-checking applet, which is easy to install and check.'

cimc-itech
Reefer Container has the advantage for platform, and the system can directly connect to the port's reefer container monitoring system. Currently, only CIMC Intelligence is doing the port's reefer container monitoring system. At present, the port terminals that have realized the docking of the port system are: Ningbo Meishan Port, Zhoushan Yongzhou Port, Guangxi Qinzhou Port, and Qingdao Port.

The communication function of Reefer Container integrates low-orbit satellite communication, and diversified communication makes Reefer Container have more advantageous to face special situations
Parameter Specification
Item Parameter Specification Item Parameter Specification
External Power Supply AC +24V1.5A Operating Temperature -20~65℃
Internal Backup Power 4.2V/6AH lithium polymer rechargeable battery, continuous working time ≦ 10 days, rechargeable times ≧ 400 times Bluetooth V5.0
GPS/Beidou Positioning Module GPS Positioning Sensitivity less than -158DBM; Positioning Accuracy ≦10 meters Bluetooth communication >15m
GSM Data Communication Module Sensitivity less than -105DBM, GSM/4G/SMS Communication Wireless Data Transmission Reporting Interval Adjustable
OG2 Satellite Module -120 dBm.(BER 1*10-5) Satellite Communication Have
Monitor the Data Transfer Cycle 5min---3hours Ad Hoc Network Have
Working Temperature、Humidity -10℃~+50℃;5% RH~95% RH Four Coolers Compatible (Carrier, Cool King, Daikin and StarCool)
Product Specifications 212.6mm x 115.3mm x 44mm Remote upgrade support
Waterproof Level IP65 Standby Time 180 days


If you want to know more reefer tracking solutions and reefer container tracking, please feel free to contact us!
