Electrically Conductive Silicone rubber ZY-2150 series
Product Quick Detail
- Packaging
- 20kg/ctn
- Delivery
- 15 Days
Specifications
Electrically Conductive Silicone rubber ZY-2150 series
Product features:
1. Significant resistance to natural aging (ray, bad weather, ultraviolet radiation, ozone, salt fog, etc.), and the climate and the industrial pollution has the very strong
resistance.
2. Significant resistance to tracking, and at the same time have excellent arc resistance and electric erosion resistance.
3. Stable physical properties and electrical properties.
Product application:
1. The cable head
2. The keyboard, button at the bottom of the contact with the conductor
3. Copy machine roller
4. The wires connecting pipe
Product performance:
| projects | requirements | |||
| ZY-2140 | ZY-2150 | ZY-2160 | ZY-2170 | |
| appearance | Solid black, no obvious mechanical impurities | |||
| density，g/cm3 | 1.10±0.03 | 1.14±0.03 | 1.17±0.03 | 1.21±0.03 |
| hardness，Shore A | 40±3 | 50±3 | 60±3 | 70±3 |
| tensile strength，MPa ≥ | 4.0 | 5 | 5 | 4.5 |
| elongation，％ ≥ | 450 | 300 | 250 | 120 |
| tear strength，kN/m ≥ | 12 | 10 | 8 | 7 |
| shrinking percentage，％ | 3.4～3.8 | 3.2～3.6 | 3.1～3.5 | 2.9～3.3 |
| rebound resilience， ％ ≥ | 45 | 40 | 40 | 35 |
| volume resistivity，Ω·cm3≤ | 15 | 12 | 10 | 5 |
| surface resistance， Ω ≤ | 400 | 200 | 150 | 80 |
