Slotted Bridge Water Well Screen Pipes
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Victall offers high quality well screen and parts including slotted pipes for bridge water well screen. Bridge well screen pipes are mostly slotted stainless steel with precise slot holes.
Technical Parameters of Bridge Water well screen slot pipes:
Screen pipe Sizes
•OD:from 4 in to 80 in
•WT from 3 mm / 0.12 in. to 10mm / 0.4 in.
•lengths up to 6m
Well Screen Bridge Pipe Materials of Construction:
•All types of steel such as carbon steel, galvanized steel, coated steel and stainless steel types 304, 304L, 316, 316L & 430, for example.
Strainer pipe Slot Sizes:
•Between 0.5 mm / 0.002 in. and 5mm / 0.2 in., depending on the wall thickness.
Material 304.316 steel
OD(mm) 146.159.219.273.325.377.426.529
WT(mm) 5-8
Length up to 6 m
Surface treatment painting or galvanzied
End connection plain beveled or flanged or couplings
Advantage of the bridge slot water well screen tubes:
1.high strength well screen
2.long usage time bridge slot screen
3.thin weight
4.low cost screen pipe
5.easier operation to save more time
6.custom made to meet your require better
Application:
This type of bridge slot screen pipe is used in projects of water wells, mining & Mineral Processing, municipal water supply, refining & petrochemical, water treatment, architecture and construction, etc.
