Key Specifications/Special Features:
Good quality and affordable stainless steel wire
1.Tolerance:±0.003mm or as required
2.Brand Name:Bashan
3. Place of Origin:Henan, China (Mainland)
4. Certification: ISO9001, SGS, CTI, ROHS
Bashan company mainly supplies SS wire 300 & 400 series.
Φ5.5mm-0.02mm
Product Name | China Manufacturer HQ Stainless Steel Fine Wire |
Material | SUS304, SUS316L imported from Japan and France |
Standard | AISI, ASTM, SUS, DIN, JIS, GB, UNS. |
Weight/Spool | 500g-2kg/spool, |
Tensile strength | above 70Mpa |
Spool type | OR80, OR115, HK100 |
Elongation | above 25% |
Applications | wire mesh weaving, textile fabric like radiation resistant shield clothing |
Chemical Composition for China Manufacturer HQ Stainless Steel Fine Wire .
And the form is as follows:
Chemical Composition for Types of Stainless Steels | ||||||||
Type AISI | C Max % | Mn Max % | P Max% | S Max% | Si Max % | Cr % | Ni % | Mo % |
304 | <0.08 | <2.00 | <0.045 | <0.03 | <1.00 | 18.00-20.00 | 8.0-10.50 | _ |
304L | <0.03 | <2.00 | <0.045 | <0.03 | <1.00 | 18.00-20.00 | 9.0-13.0 | _ |
308 | <0.08 | <2.00 | <0.045 | <0.03 | <1.00 | 19.00-21.00 | 10.0-12.0 | _ |
316 | <0.08 | <2.00 | <0.045 | <0.03 | <1.00 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
316L | <0.03 | <2.00 | <0.045 | <0.03 | <1.00 | 16.00-18.00 | 12.00-15.00 | 2.00-3.00 |
321 | <0.08 | <2.00 | <0.045 | <0.03 | <1.00 | 17.00-19.00 | 9.0-13.0 | _ |
410 | <0.15 | <1.00 | <0.040 | <0.03 | <1.00 | 11.50-13.50 | <0.6 | _ |
430 | <0.12 | <1.00 | <0.040 | <0.03 | <0.75 | 16.00-18.00 | <0.6 | _ |
Packing & Transport:
hina Manufacturer HQ Stainless Steel Fine Wire
- Packed with woven flexible belt.
- Shrink film outside, paper carton, wooden box.
Our Company:
Xinxiang Bashan Aero Material CO., LTDhttp://www.bashanwiremesh.com
In more than 62 years experience of metal wire cold drawing, metal wire mesh weaving and deep processing products, Bashan company acquired 24 metal wire & mesh patents and took chief part of 19 standards, such as GB/T4240, GB/T5330, GB/T6003, GJB107, HB1862, etc.
Bashan factory affiliated to China Aviation Industry Corporation (AVIC), is the only professional military manufacturer of stainless steel wire, metal wire mesh, filter element, special filtration component and wire thread insert.
1) 800 tons of stainless steel wire of medium and fine wire.3600 tons of coarse wire above 1mm in diameter
2) 500 thousand square meters of high precision wire cloth in nominal aperture sizes from 6.00 to 0.02mm.
3) 10 million pieces of thread inserts, including free run type and screw-locking type with ranges of M2-M45mm.
