PCBA Electronical Manufacturing Service Provider Makerfabs

Place Of Origin
China (Mainland)
Minimum Order
1
Packaging
1pcs per ESD vacuum packing
Delivery
15 Days
Makerfabs provides the turnkey service for makers& startups to create the first prototyping board to the mass production, includes the PCB/ Components Sourcing/ Soldering/ Programming/ Testing and end shipping. Our responsive team will offer you PCB assembly services with a range of process control, refined and strict PCB assembly workflow and quality commitment. With this service, you do not need to suffer from these very detailed work such as soldering the prototype board, and thus can concentrate on the creating and designing.

How to use Makerfabs PCBA service:

1.Send your request to us for quotation. For PCB Assembly work, please send us:

  • PCB Gerber Files, and the quantity you need and related spec such as color/ pads finish/ layers, etc.
  • BOM Files, some reference link or digikey/ farnell parts number would be help for our quotation.
  • Files for the soldering such as parts mapping for pick-n-place machine, or a simple mapping for hand soldering.
  • Programming/ Testing method, Makerfabs will help testing all the PCBA to ensure you 100% pass.
  • Other files that you want us know to avoid mistakes in the production.
  • 2. Makerfabs will make you quotation in 2 working days.

    3.Custom’s checking on the quotation and confirmation, and negotiation if needed.

    4.Makerfabs works on the project.

    5.Shipping, customer’s checking, and projects closed if all OK.


    Makerfabs PCBA Manufacturing Capabilities :


    1. Lead Time:

    Normally the prototyping project would be completed in 12 working days, and project for more than 50 pcs needs 15 working days. But the detailed lead time depends on many factors such as the components sourcing difficulty/ testing time, so the final lead time many altered for each projects. We will keep you in touch in the whole process of production.

    2.Components Preparing:

    Makerfabs help sourcing/ purchasing components with your detailed part list. We will prepare the components from official Authorized distributors or international distributors such as Mouser

    We also accept customer sending package to us for assembly.

    3. PCB Assembly and Price

    Projects will be soldered manually or by pick-n-place machine, depends on the projects quantity and soldering difficulty. Basically, for prototyping board<10 pcs, will be soldered by hand, while by machine with higher quantity. The price would be 0.03$ for each pads, both for SMD pads or THT pads. Note that a stencil would be needed for SMD soldering, even for hand soldering.

    As the components, we can solder the most common used package such as 0201/0402/0603/QFP/QFN/BGA/THT. All the assembly fee would be calculated and quoted by our projects manager so you will have a very detailed quotation before your decision.

    4. Quality Control

    Makerfabs have strict quality control procedure, including test plan, supplier qualification, incoming material inspection, first article inspection, visual inspection, 100% functionality testing and outgoing quality inspection before shipping. Makerfabs engineers have many years of quality control experience in small batch production.

    We do inspection mainly according to IPC-A-610E and GB2828 sampling standard.

    5. Quality Assurance

    Makerfabs cherish every relationship with customers and servers every customers by heart. Will 100% responsible for the mistakes/ faults in the production. If there is indeed some problems in our production lead to your lost, you can directly contact your project manager
    to request re-production or even refunding.

    Makerfabs would be glad to hear your suggestions/ complains if not satisfied, and your recommends to your friends with your satisfaction.
  • Country: China (Mainland)
  • Business Type: Manufacturer,Trading Company,Distributor/Wholesaler
  • Market:Americas,Europe,Asia,Middle East
  • Founded Year:2015
  • Address:401, Huashenghui Office Building, Jinhai Rd, Xixiang Street, Bao'an District
  • Contact:Helen He
