TP03DA24S05 ,3W 18-36VDC input ,5VDC output dc dc converter

Minimum Order
100
Place Of Origin
CHINA
FOB Price
USD $6.00 / Piece
Packaging
30/TUBE
Delivery
15 Days
TP03DA24S05 ,3W 18-36VDC input ,5VDC output dc dc converter


The rated output power of TP03DA/Y converters is 3W,the outline dimensions is "31.75*20.32*11.2",
4:1 wide input voltage range,the voltage range is 9V-36V and 18V-72VDC.
The accuracy of the converter can reach ±1% ,It can be widely used in telecommunications, railway transportation, instrument and etc.

3W output power
4:1 wide input voltage range
Over load protection

31.75mm*20.32mm*11.2mm standard package


Fixed switching frequency
Operating temperature: -40℃to 85℃
Metal shell packaging
RoHS compliant
3KVDC isolated optional


Part Number Input Vlotage Output
voltage(VDC) Voltage(VDC)
Rated Range values
TP03DA05S05 5(2:1) 4.5-9 5
TP03DA05D05 5(2:1) 4.5-9 ±5
TP03DA12S03 12(2:1) 9-18 3.3
TP03DA12S05 12(2:1) 9-18 5
TP03DA12S12 12(2:1) 9-18 12
TP03DA12S15 12(2:1) 9-18 15
TP03DA12D05 12(2:1) 9-18 ±5
TP03DA12D12 12(2:1) 9-18 ±12
TP03DA12D15 12(2:1) 9-18 ±15
TP03DA24S03 24(2:1) 18-36 3.3
TP03DA24S05 24(2:1) 18-36 5
TP03DA24S12 24(2:1) 18-36 12
TP03DA24S15 24(2:1) 18-36 15
TP03DA24D05 24(2:1) 18-36 ±5
TP03DA24D12 24(2:1) 18-36 ±12
TP03DA24D15 24(2:1) 18-36 ±15
TP03DA48S03 48(2:1) 36-72 3.3
TP03DA48S05 48(2:1) 36-72 5
TP03DA48S12 48(2:1) 36-72 12
TP03DA48S15 48(2:1) 36-72 15
TP03DA48D05 48(2:1) 36-72 ±5
TP03DA48D12 48(2:1) 36-72 ±12
TP03DA48D15 48(2:1) 36-72 ±15
TP03DA24S05W 24(4:1) 9-36 5
TP03DA24S12W 24(4:1) 9-36 12
TP03DA24S15W 24(4:1) 9-36 15
TP03DA24D05W 24(4:1) 9-36 ±5
TP03DA24D12W 24(4:1) 9-36 ±12
TP03DA24D15W 24(4:1) 9-36 ±15
TP03DA48S05W 48(4:1) 18-72 5
TP03DA48S12W 48(4:1) 18-72 12
TP03DA48S15W 48(4:1) 18-72 15
TP03DA48D05W 48(4:1) 18-72 ±5
TP03DA48D12W 48(4:1) 18-72 ±12
TP03DA48D15W 48(4:1) 18-72 ±15
