Machine Parameter
Item |
Weaving Width
(mm) |
Wire Diameter
(mm) |
Mesh
Size (mm) |
Power
(v) |
Weaving
Speed (T/Min) |
Weave
Type |
Weight
(KG) |
Outsize
(mm) |
1300B | 1300 | 0.025-0.3 | 40-400 |
380V
2.2KW |
75-78 | Plain and Twill | 3000 | 2600x2800x1200 |
1300D | 1300 | 0.1-0.4 | 20-80 |
380V
4KW |
53 | Plain and Twill | 3400 | 2569x3535x1849 |
1300Q | 1300 | 0.1-0.6 | 10-40 | 380V 2.2KW | 53 | Plain | 3500 | 2569x3535x1849 |
1300QD | 1600 | 0.8-1.6 | 4-40 |
380V
5.5-7.5KW |
53 | Plain | 9000 |
2600x2800x1200 |
1, Maintenance period: one year
We can send our technicist to the buyers\' place to debug the machine and providing the training
in 30 days after the machines arrive at the destination port.
2, The debugging fees: free
3, The training fees: First 7days is free , after that USD100/day for each technical
4, The numbers of technical persons: one technical person per machines at most.
5, The fees: round-trip tickets, accommodation etc, are all in buyers\' account.
6, During the maintenance period: the parts damaged non-artificially will be provided free of charge. If
buyers need the technicians,we will assign the technical staff to your company. And the fees ,
such as round-trip tickets,accommodation etc, are all in buyers\' account.
7, After the maintenance period: If buyers need the machine parts, we will provide it as our cost.
If buyers need the technicians, we will assign the technical staff to your company. And the fees ,
such as round-trip tickets,accommodation etc, are all in buyers\' account.
