SWM265P156 SPECIFICATION:
ELECTRICAL DATA @ STC
Peak Power Watts Pmax(WP): 265
Power Output Tolerance Pmax(%):+3
Maximum Power Voltage Vmp(V):31.4
Maximum Power Current IMPP(A):8.44
Open Circuit Voltage Voc(V):38.6
Short Circuit Current Isc(A):9.03
Module Efficiencyηm(%): 16.2
Values at Standard Test Conditions STC(Air Mass AM1.5,Irradiance 1000W/㎡。Cell Temperature 25℃)
ELECTRICAL DATA @NOCT
Maximum Power Pmax(Wp): 197
Maximum Power Voltage Voc(V):29.0
Maximum Power Current Impp(A):6.78
Open Circuit Voltage Voc(V):35.3
Short Circuit Current Isc(A):7.36
NOCT: Irradiance at 800W/㎡,Ambient Temperature 20℃,Wind Speed 1m/s
MECHNICAL DATA
Solar Cells: Mono-crystalline 156*156mm(6 in)
Cell Orientation: 60 cells(6*10)
Module Dimensions: 1640*992*35mm(62.2*41.89*1.57 in)
Weight: 18.5kg(40.79 Ib)
Glass: High transparency solar glass 4.0mm(0.16 in)
Frame: Anodized aluminum alloy
J-Box: IP 65 rated
Cables: Photovoltaic technology cable 4.0mm²(0.0062 in²)
Connector: Original MC4 PLUS
TEMPERATURE RATINGS
Nominal Operating Cell Temperature(NOCT): 45℃(±2℃)
Temperature Coefficient of Pmax: -0.43%/℃
Temperature Coefficient of Voc: -0.32%/℃
Temperature Coefficient of Isc: 0.04%/℃
MAXIMUM RATINGS
Operational Temperature: -40℃~+85℃ 10 Year Product
Maximum System Voltage: 1500V DC(IEC)/ Workmanship Warranty
1000V DC(UL) 25 Year Linear Power
Max Series Fuse Rating: 15A Warranty
