Polyester screen printing mesh
Product Quick Detail
- Place Of Origin
- China
- Minimum Order
- 1
- Packaging
- Carton box
- Delivery
- 5 Days
Specifications
1) Clearly Target
Please advise me the specification, I will offer best price!
2)Unclearly Target
Please advise me your application, I can offer you some advise with my speciality!
Product Description:
Mesh Count: 8T-165T
Color: yellow, white
Width: 0.6m-3.6m
Length per roll: 30m, 50m, 30yard, 60yard or by customer's request
Mainly market : Our mesh sells good all around the world. Such as: North America (USA, Canada, Mexico), South America( Braizil, Chile, Argentina, Peru etc.), European country (Germany, France, Italy,Poland, etc.), Asia (UAE, Iraq, Iran, Thailand, Vietnam , Malaysia, Turkey, Pakistan, Bangladesh etc. )
Parameter:
Mesh Count weaving Thread Diameter/um Pening um Open Area% Tension N/cm
10T 1:1PW 250 740 53 6012T 1:1PW 150 522 47 62
16T 1:1PW 200 435 47 48
16T 1:1PW 100 450 70 48
20T 1:1PW 100 410 68 49
24T 1:1PW 100 323 58 50
24T 1:1PW 120 303 51 48
27T 1:1PW 100 270 58 46
32T 1:1PW 71 230 60 28
32T 1:1PW 64 245 61 28
32T 1:1PW 100 200 43 42
36T 1:1PW 100 182 42 42
39T 1:1PW 55 199 61 32
39T 1:1PW 80 172 46 42
43T 1:1PW 80 151 43 36
47T 1:1PW 55 157 55 32
48T 1:1PW 71 141 44 32
53T 1:1PW 55 133 50 34
55T 1:1PW 55 126 49 32
55T 1:1PW 64 115 39 30
59T 1:1PW 55 101 42 33
64T 1:1PW 55 104 43 33
64T 1:1PW 64 95 36 35
72T 1:1PW 48 96 46 32
72T 1:1PW 55 80 30 32
77T 1:1PW 55 75 28 33
80T 1:1PW 48 78 30 29
90T 1:1PW 48 55 26 32
100T 1:1PW 40 58 32 27
110T 1:1PW 40 48 27 30
120T 1:1PW 34 45 30 26
120T 1:1PW 40 40 20 27
140T 1:1PW 34 32 19 31
150T 1:1PW 34 26 20 31
1.100% Polyester Material
2.Plain Weave, Low Elongation
3.Excellent Tear Resistance
4.Excellent Dimensional Stability
5.Higher Tension Strength & Break Point
6.Low Elongation
- Country: China (Mainland)
- Business Type: Manufacturer
- Market:Americas,Asia,Emerging Markets
- Founded Year:2010
- Address:No. 20-1, Siyuan Road, Yexie Town, Songjiang District
- Contact:Andrew Zhao
