Screen printing exposure unit
Product Quick Detail
- Minimum Order
- 1
- Place Of Origin
- China
- Packaging
- 1pcs in wooden box
- Delivery
- 15 Days
Specifications
Application scope:
This series suitable for high precision screen plate exposure.
Specification:
1.Controlled by microcomputer, 10 groups freely adjust memory mode, screen exposure, extraction, exhaust one time make it, easy to operateã
2.Equipped with automatic window shutter, built-in ventilation cooling system, heat tube can be send out in a timely manner so as to prolong the service life of tubes, to achieve the best exposure effect.
3.With automatic voltage regulation device to guarantee the accuracy of the exposure, using powerful vacuum pump, the suction vacuum degree can reach 0.8 Mpa, instant fixed screen.
4.Using high quality iodine gallium light, durable and spectrum stability, effectively ensure the quality of exposure.
5.Chimney choose advanced refraction mirror aluminum, tubes can be refracted to four angles, to ensure uniform illumination intensity.
Parameter:
| Model | EG-1012 | EG-1315 |
| Exterior size | 1000 X 1200mm | 1300 X 1500mm |
| Effective exposure area | 800 X 1000mm | 1100 X 1300mm |
| Vacuum pump | High pressure | |
| Exposure type | Quick start | |
| Cooling way | Forced air cooling | |
| Uï¼V light | Hg 2kW lamp | Hg 3kW lamp |
| Power | 220V X 1p X 3kW | 220V X 1p X 3.5kW |
| Dimension(W X D X H) | 1000 X 1200 X 1090mm | 1300 X 1500 X 1090mm |
| â Special specification can be made for customized requirement. |
